Wide Angle Lens – C0811014M20

C0811014M20 is Wide-angle lens 1.1″ C-Mount HD lens, 8mm Low distortion lens, manual iris, High resolution 20-Megapixel, F1.4~16 aperture.

For engineers comparing sensor coverage and focal length requirements, the FOV Calculator can help estimate the relationship between sensor size, focal length, and field of view.

1.1″ 20MP 8mm C-Mount Wide Angle Machine Vision Lens

This 1.1-inch 20MP C-Mount machine vision lens combines an 8mm focal length with a wide 98.5° diagonal field of view, making it suitable for high-resolution industrial imaging where a broad scene must be captured without sacrificing image detail. With an F1.4–16 manual aperture and 0.1m minimum object distance, it provides flexible imaging control for demanding machine vision and industrial inspection systems.

The lens is designed for large-format 1.1-inch sensors and supports resolutions up to 20MP, making it a practical choice for high-resolution inspection, automated imaging, robotics vision, and other industrial camera systems requiring a wide-angle C-Mount optical solution.

Product Highlights at a Glance

• 20MP high-resolution imaging for demanding industrial camera systems.
• 98.5° diagonal FOV provides broad scene coverage with an 8mm focal length.
• 1.1-inch image format supports large-format high-resolution sensors.
• F1.4–16 manual aperture enables flexible exposure and depth-of-field control.
• 0.1m M.O.D. supports relatively close-range industrial imaging applications.

C-Mount Wide Angle Machine Vision Lens Applications

Core Application Scenes

This 20MP C-Mount wide angle machine vision lens is particularly suited to industrial imaging systems where the camera needs to capture a relatively large working area while maintaining high image resolution. Its 8mm focal length and 98.5° diagonal FOV make it useful for applications where a conventional longer-focal-length lens would provide insufficient scene coverage.

In automated inspection environments, the lens can be used to image large components, assemblies, work surfaces, or production areas from a relatively short camera-to-object distance. The 0.1m minimum object distance also provides flexibility for compact inspection setups where the camera must operate close to the target.

For robotics, the broad FOV can help vision systems observe a larger area around the robot or workpiece. The combination of 20MP resolution and manual optical adjustment also allows system integrators to balance image detail, exposure, and depth of field during installation.

For a broader overview of industrial imaging configurations, see Machine Vision Solutions and Robotics Vision Solutions.

Compatible Device List

• Industrial Cameras: Designed for C-Mount industrial cameras equipped with compatible 1.1-inch image sensors and resolutions up to 20MP.
• Machine Vision Systems: Suitable for automated inspection cameras requiring wide-area image capture and high-resolution optical performance.
• Factory Automation Equipment: Can be integrated into inspection stations, production-line cameras, and automated optical inspection equipment when the working distance and FOV requirements match.
• Robotic Vision Systems: The wide field of view can help robotic cameras observe larger work areas, components, or operating zones.
• High-Resolution Embedded Imaging: Suitable for industrial imaging platforms where a large-format sensor and wide-angle optical configuration are required.
• Optical Integration: Manual iris and manual focus allow engineers to adjust the lens during system setup according to lighting and working-distance conditions.

When selecting a C-Mount lens for a specific sensor, engineers should verify image format, image circle, focal length, and field of view together. The Sensor Guide provides additional information for matching lenses with camera sensors, while the Lens Selection Guide can be used when comparing different industrial lens configurations.

Designed for high-resolution wide-area machine vision, industrial inspection, factory automation, and robotic imaging applications.

Frequently Asked Questions

Q: What type of camera is this 20MP lens designed for?
A: This lens features C-Mount and is engineered for industrial cameras with compatible 1.1” sensors. Its 20MP capacity suits high-resolution machine vision and industrial imaging systems.

Q: What is the field of view of the 8mm C-Mount lens?
A: Per provided specs, the lens delivers 98.5° diagonal, 85° horizontal and 68° vertical FOV. Actual coverage also depends on camera sensor dimensions.

Q: Is this lens suitable for machine vision applications?
A: Yes. The 1.1” format, 20MP resolution, C-Mount interface, wide FOV and manual optical controls suit diverse machine vision and industrial inspection systems.

Q: What is the minimum object distance of this lens?
A: The specified M.O.D. is 0.1m, or 100mm. This makes the lens suitable for imaging applications where the camera operates relatively close to the target.

Q: Can the aperture be adjusted manually?
A: Yes. The lens has a manual iris with an aperture range from F1.4 to F16, allowing users to adjust light transmission and depth of field according to the application.

Q: Does this lens have low distortion?
A: Specified TV distortion is below 5.5%, delivering defined distortion performance for wide-angle imaging. It cannot be automatically regarded as an ultra-low-distortion lens without application-specific optical requirements.

Q: Is the lens suitable for robotics vision?
A: Yes. Its wide 98.5° diagonal FOV enables robotic vision systems to capture a larger working area, and 20MP resolution delivers detailed imagery for inspection and visual guidance.

Q: How can I determine whether this 8mm lens provides the required image coverage?
A: Image coverage depends on sensor dimensions, focal length, and working distance. You can use the FOV Calculator to estimate the required field of view before selecting the lens.
