Low Distortion Lens – S25012701420

S25012701420 is Low distortion 1/2.7″ M12-mount 2-Megapixel lens with 25mm focal length, 16° diagonal F.O.V., F2.0 aperture, Suitable for security Surveillance.

25mm M12 2MP Low Distortion Industrial Lens

This 25mm M12 lens is a fixed focal length industrial lens designed for 1/2.7″ 2MP image sensors. With a 16° diagonal field of view, F2.0 fixed aperture, and less than 3% distortion, it provides a narrow, controlled viewing area for compact machine vision, embedded imaging, and fixed-target industrial camera applications.

Product Highlights at a Glance

• 25mm fixed focal length for narrow-area imaging.
• 2MP resolution matched to 1/2.7″ image sensors.
• <3% distortion for controlled image geometry.
• F2.0 fixed aperture for consistent optical configuration.
• M12 × 0.5 mount for compact embedded camera systems.

25mm M12 Low Distortion Lens Applications

Core Application Scenes

This 25mm M12 low distortion lens is designed for imaging systems that need to concentrate on a defined target area rather than capture a wide scene. Its 25mm focal length produces a 16° diagonal FOV on a 1/2.7″ sensor, making it suitable for applications where the camera is positioned at a moderate working distance and the target occupies a relatively focused portion of the image.

The less-than-3% distortion specification helps maintain controlled image geometry across the captured scene. This makes the lens suitable for fixed-position inspection, object recognition, code reading, and embedded industrial cameras where consistent imaging performance is more important than wide-area coverage.

The F2.0 fixed aperture provides a straightforward optical configuration for compact camera modules, while the M12 × 0.5 mount supports integration into small camera housings and embedded vision equipment. With a 0.5m minimum object distance, the lens is particularly suitable for applications where the camera is installed at a defined distance from the inspection target.

For engineers determining whether a 25mm focal length provides sufficient coverage, the FOV Calculator can be used to estimate the visible area based on sensor and working-distance requirements. The Focal Length Calculator can also help compare alternative focal lengths during camera system design.

Compatible Device List

• Compact Machine Vision Cameras: Suitable for 1/2.7″ 2MP camera modules requiring a relatively narrow field of view.
• Embedded Inspection Cameras: The M12 × 0.5 interface allows integration into compact industrial imaging assemblies.
• Fixed-Position Inspection Systems: The 25mm focal length is appropriate for applications where the camera-to-target distance remains controlled.
• Object Recognition Equipment: The narrow FOV helps concentrate image coverage on a defined inspection or recognition area.
• Code Reading Systems: Suitable for fixed camera installations where controlled viewing geometry is required.
• OEM Vision Devices: The compact optical configuration can be integrated into customized camera housings and embedded imaging equipment.

Designed for fixed-target industrial inspection, embedded vision, and controlled-area machine vision applications.

Frequently Asked Questions

Q: What sensor size is this 25mm M12 lens designed for?
A: This lens is designed for a 1/2.7″ image format and supports 2MP resolution.

Q: What is the field of view of the 25mm M12 lens?
A: On a 1/2.7″ sensor, it provides a 16° diagonal FOV, 14° horizontal FOV, and 8° vertical FOV.

Q: Is this a low distortion lens?
A: Yes. The specified distortion is less than 3%, providing controlled geometric distortion for industrial and embedded imaging applications.

Q: What aperture does this lens use?
A: The lens has a fixed F2.0 aperture. Its fixed iris configuration provides a consistent optical setup for applications with controlled lighting conditions.

Q: What is the minimum object distance?
A: The specified minimum object distance is 0.5m. The actual recommended working distance should be determined according to the target dimensions, sensor characteristics, and required image coverage.

Q: Is this lens suitable for machine vision?
A: Yes. Its 25mm focal length, 2MP resolution, controlled distortion, and compact M12 mount make it suitable for selected fixed-position machine vision and industrial inspection systems.

Q: What type of camera uses this M12 lens?
A: It can be integrated into compact cameras and embedded vision modules using an M12 × 0.5 lens interface, particularly systems based on 1/2.7″ image sensors.

Q: How do I determine whether the 25mm focal length is suitable for my application?
A: Focal length selection depends on sensor size, working distance, and the required field of view. The Lens Selection Guide and Sensor Guide provide useful information for system design. For application-specific requirements, you can also contact TOWIN.
