CCL14037MP
3.7mm low distortion lens, F1.8 M12/S-mount wide-angle lens, 1/4″ high resolution 5 Megapixel CCTV lens.
CCL14037MP is 3.7mm High-Quality low distortion lens, F1.8 Low F-number M12/S-mount wide-angle lens, 1/4″ high resolution 5 Megapixel CCTV lens.
| IMAGE FORMAT | 1/4″ |
| FOCAL LENGTH | 3.7mm |
| F.O.V. | 78°(D=4.8) |
| 62°(H=3.84) | |
| 45.5°(V-2.88) | |
| DISTORTION | <-11% |
| RESOLUTION | 5MP |
| APERTURE | F1.8 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| FOCUS | Manual |
| ZOOM | Fixed |
| B.F.L. | 5.48mm |
| M.O.D. | 0.3m |
| CONSTRUCTION | 6G |
