Low Distortion Lens – C252314A2IR

C252314A2IR is C-Mount 25mm low distortion lens, 2-Megapixels resolution, DC Auto iris, F1.4-C large aperture Suitable for low-light environments.

25mm C-Mount Low Distortion Lens

This 25mm C-Mount fixed focal lens is designed for 2/3″ and 1/2″ camera sensors, delivering controlled fields of view with distortion below -1%. Its F1.4–C aperture, DC auto iris, manual focus, and 0.5m minimum object distance make it a flexible industrial lens for factory automation, machine vision, and professional surveillance systems.

For help matching the lens with a camera sensor, the Sensor Guide explains important sensor and image-format considerations. You can also use the Lens Selection Guide when selecting focal length and lens characteristics for a specific imaging system.

Product Core Highlights

• 25mm fixed focal length for stable, repeatable imaging.
• 2/3″ and 1/2″ FOV specifications for flexible camera integration.
• 2MP resolution for standard industrial and surveillance imaging.
• F1.4–C aperture range with DC auto iris control.
• Less than 1% distortion for controlled image geometry.

As part of the C-Mount Lenses range, this lens provides a practical optical configuration for systems that need a standard C-Mount interface, automatic iris control, and consistent framing from a fixed 25mm focal length.

C-Mount Low Distortion Lens Applications

Core Application Scenes

This 25mm C-Mount industrial lens is well suited to fixed-position imaging systems where the camera needs to maintain a consistent view of a defined inspection or monitoring area. Its 25mm focal length provides a moderately narrow field of view, making it appropriate for observing individual work areas, equipment sections, production components, or controlled access points.

In factory automation, the lens can be integrated into inspection stations where a camera is permanently mounted above or beside a production line. The fixed focal length helps maintain consistent image composition between inspection cycles, while the manual focus allows the installer to optimize sharpness during initial system setup.

The lens supports FOV specifications for both 2/3″ and 1/2″ sensors, giving system integrators more flexibility when selecting compatible industrial cameras. This is particularly useful when an existing camera platform needs to be replaced or upgraded without completely redesigning the optical configuration.

Its DC auto iris provides automatic aperture adjustment as illumination changes. This makes the lens practical for industrial environments where lighting may vary because of production-area illumination, equipment movement, or changes between different operating conditions.

With distortion below -1%, the lens can also be considered for applications where image geometry should remain relatively controlled, such as component positioning, visual verification, edge inspection, and equipment monitoring.

For projects where the required viewing area needs to be determined from sensor size and working distance, the FOV Calculator can help estimate the field of view before selecting the final optical configuration.

Designed for fixed-position factory automation, equipment inspection, and controlled industrial surveillance applications.

Compatible Device List

• 2/3″ Industrial Cameras: Suitable for C-Mount cameras using 2/3″ sensors and requiring a 25mm fixed focal configuration.
• 1/2″ Cameras: The specified 1/2″ FOV makes the lens suitable for compatible smaller-format camera systems.
• FA Inspection Equipment: Can be integrated into automated inspection stations for component verification, positioning, and production monitoring.
• Machine Vision Cameras: Suitable for standard 2MP industrial vision applications where fixed framing and automatic iris control are required.
• Industrial Monitoring Systems: Appropriate for monitoring equipment, workstations, production zones, and controlled industrial areas.
• Security Cameras: The C-Mount interface and DC auto iris make the lens compatible with certain professional CCTV camera configurations.
• Fixed Installation Systems: Manual focus allows installers to establish the required focus at the selected working distance, while the fixed focal length maintains consistent framing.

For broader application information, see Machine Vision Solutions for automated inspection systems or Smart Security Solutions for industrial surveillance applications.

If you require a different sensor format, focal length, iris configuration, mechanical structure, or other application-specific optical specifications, you can contact Towin Lens for further technical consultation.

Frequently Asked Questions

Q: What sensor sizes can this 25mm C-Mount lens support?
A: The supplied specifications provide FOV data for both 2/3″ and 1/2″ sensors, making the lens suitable for compatible camera systems using either image format.

Q: What is the field of view on a 2/3″ sensor?
A: On a 2/3″ sensor, the lens provides a 24° diagonal, 19° horizontal, and 14.5° vertical FOV.

Q: What is the field of view on a 1/2″ sensor?
A: On a 1/2″ sensor, the specified FOV is 18° diagonal, 14.5° horizontal, and 11° vertical.

Q: Is the 25mm focal length fixed?
A: Yes. This is a fixed focal lens, providing consistent optical framing for fixed-position imaging applications.

Q: Does this lens have an automatic iris?
A: Yes. It uses a DC auto iris, allowing the camera system to automatically adjust the aperture in response to changing illumination.

Q: What is the maximum aperture?
A: The maximum aperture is F1.4, with an adjustable range of F1.4 to C. This provides flexibility for different lighting and depth-of-field requirements.

Q: Is this lens suitable for machine vision applications?
A: Yes. The 25mm focal length, 2MP resolution, C-Mount interface, low distortion, and DC auto iris make it suitable for various fixed-position machine vision and FA applications.

Q: What is the minimum object distance of this lens?
A: The specified M.O.D. is 0.5m, making it suitable for imaging applications where the target is positioned at or beyond this minimum object distance.
