S08012004812IR
Low-distortion M12-mount CCTV lens with 60° diagonal FOV, 640×480 resolution, F1.2 aperture, and 940nm IR filter for 1/2″ sensor security surveillance.
S08012004812IR is Low-distortion M12-mount CCTV lens with 60° diagonal FOV, 640×480 resolution, F1.2 aperture, and 940nm IR filter for 1/2″ sensor security surveillance.
| IMAGE FORMAT | Max Φ8.5mm |
| FOCAL LENGTH | 8.0mm |
| F.O.V. (1/2″, MLX75027) | 60°(D) |
| 48°(H) | |
| 36°(V) | |
| DISTORTION | <-10% |
| RESOLUTION | 640*480 |
| APERTURE | F1.2 |
| MOUNT | M12X0.5 |
| IRIS | Fixed |
| F.B.L. | 1.89mm |
| M.O.D. | 0.2m |
| C.R.A. | <29° |
| FILTER | 940nm BPF |
