FA Lens – C352328M10

C352328M10 is Industrial lens 2/3″ 35mm C-Mount FA lens, 10 Megapixel low-distortion lens, manual iris, F2.8~16, High-Resolution Telephoto lens.

35mm F2.8–16 10MP C-Mount Low Distortion FA Lens

This 35mm C-Mount industrial FA lens is designed for 2/3″ sensors and supports up to 10MP resolution with TV distortion below 0.1%. With a narrow 16° diagonal field of view, manual iris and focus control, and a 0.1m minimum object distance, it is well suited to precision inspection where controlled framing and accurate image geometry are required.

Product Highlights at a Glance

• 10MP resolution supports detailed imaging for demanding industrial inspection.
• <0.1% TV distortion helps preserve accurate object geometry and dimensional relationships.
• 35mm focal length provides a narrow field of view for controlled target framing.
• F2.8–16 manual iris enables flexible exposure and depth-of-field adjustment.
• C-Mount interface is compatible with a broad range of industrial cameras.

C-Mount FA Lens Applications

Core Application Scenes

The 35mm focal length and narrow 16° diagonal field of view make this lens suitable for applications that need to isolate a relatively small inspection area while maintaining high image detail.

Typical applications include:

• Precision machine vision inspection
• Dimensional measurement
• Electronic component inspection
• PCB and assembly inspection
• Small-part inspection
• Industrial defect detection
• Product surface inspection
• Barcode and code inspection
• Factory automation systems
• Robotic vision inspection

Designed for precision industrial inspection applications where narrow-angle imaging and low geometric distortion are required.

The combination of 10MP resolution, 35mm focal length, and <0.1% TV distortion makes this lens particularly useful when accurate positioning, shape recognition, and consistent image geometry are important.

For system design guidance, see TOWIN’s Machine Vision solution and Lens Selection Guide.

Compatible Device List

• 2/3″ industrial cameras
• 10MP machine vision cameras
• C-Mount cameras
• Factory automation vision systems
• Precision measurement systems
• Robotic inspection equipment
• Industrial defect detection systems
• Automated optical inspection equipment

If your project requires another focal length or sensor format, explore the complete C-Mount Lenses range.

Frequently Asked Questions

Q: What sensor size is compatible with this 35mm lens?
A: This lens is designed for 2/3″ image sensors and supports up to 10MP resolution.

Q: What is the field of view of the 35mm lens?
A: The field of view is 16° diagonal, 13° horizontal, and 10° vertical, providing a relatively narrow viewing angle.

Q: What makes this lens suitable for precision inspection?
A: Its 10MP resolution and TV distortion below 0.1% help maintain detailed imaging and accurate geometric representation.

Q: Is the 35mm focal length suitable for close-range inspection?
A: Yes. The specified minimum object distance is 0.1m, allowing the lens to be used for relatively close inspection setups when the required field of view is appropriate.

Q: Does this lens have an adjustable aperture?
A: Yes. It features a manual iris with an aperture range of F2.8 to F16.

Q: What type of mount does this industrial lens use?
A: It uses a C-Mount interface for compatibility with C-Mount industrial cameras.

Q: Is this lens suitable for machine vision measurement?
A: Its 10MP resolution and <0.1% TV distortion make it suitable for machine vision applications where image detail and geometric accuracy are important. Final measurement performance also depends on camera resolution, working distance, lighting, calibration, and system setup.

Q: How can I determine whether 35mm is the correct focal length?
A: Focal length should be selected according to sensor size, working distance, target dimensions, and required field of view. TOWIN’s FOV Calculator and Focal Length Calculator can help with preliminary lens selection.

Related TOWIN Resources

Learn more about optical selection through TOWIN’s Knowledge Center, including the Lens Basics, Optical Design, and Distortion Guide.

For customized lens requirements, specifications, or OEM/ODM projects, visit the Contact TOWIN page.
